Technical Overview
Sound power at max. speed (2010/30/EC)
64 dB
Max. air extraction
328 m³/h
Color body
Silver metallic
Built-in / Free-standing
Built-in
Highlights
Special Features
maximal extractor performance with little noise cleans the air, captures grease, easy monthly clean-up. Color body
Silver metallic
Installation typology
Built-in
Operating Mode
Convertible
Total power of the motors
90 W
Type of control setting and signalling devices
Rocker switches
Number of speed settings
2
Max. air extraction
328 m³/h
Sound power at max. speed (2010/30/EC)
64 dB
Max. air recirculation
231 m³/h
Grease filter material
Washable aluminium
Total annual energy consumption
41.1 kWh/annum
Width of the appliance
598 mm
Depth of the product
290 mm
Minimum distance above an electric hob
430 mm
Minimum distance above a gas hob
650 mm
Diameter of air outlet
120 / 150 mm
Length electrical supply cord
175.0 cm
Minimum width for installation
526 mm
Maximum width for installation
526 mm
Depth for installation
290 mm
Extremely quiet - EcoSilence Drive
No
Total power of the lamps
3 W
Color temperature
Neutral (3.500 K)
Connected appliances with Home Connect
No
Cooktop-based hood control
No
