Technical Overview
Sound power at max. speed (2010/30/EC)
64 dB
Max. air extraction
328 m³/h
Color body
Silver metallic
Material body
zinc plated
Built-in / Free-standing
Built-in
Width
60 cm
Highlights
Awards
Specifications
Width
60 cm
Color body
Silver metallic
Installation typology
Built-in
Operating Mode
Convertible
Total power of the motors
90 W
Type of control setting and signalling devices
Rocker switch
Number of speed settings
2
Max. air extraction
328 m³/h
Sound power at max. speed (2010/30/EC)
64 dB
Max. air recirculation
231 m³/h
Grease filter material
Washable aluminium
Total annual energy consumption
41.1 kWh/annum
Height of the appliance
203 mm
Width of the appliance
598 mm
Depth of the product
290 mm
Height of the chimney
GENERAL.N_A mm
Minimum distance above an electric hob
430 mm
Minimum distance above a gas hob
650 mm
Diameter of air outlet
120 / 150 mm
No-return airflow flap
No
Length electrical supply cord
175 cm
Net weight
8.5 kg
Minimum width for installation
526 mm
Maximum width for installation
526 mm
Depth for installation
290 mm
1 / 0
Automatic air sensor
No
Extremely quiet and powerful brushless BLDC motor
No
Extremely quiet
No
Clean filter reminders
No
Boost position
No
Delay Shut off modes
No
Remote control
No
Type of lamps used
LED
Total power of the lamps
3 W
Color temperature
Neutral (3.500 K)
Ambient light
No
Connected appliances with Home Connect
No
Cooktop-based hood control
No
